PA/Nylon Vacuum Bagging Film

Model: STR-04.015

Overview

Sentrui Vacuum Bagging Film is a high-performance, multi-layer co-extruded Nylon-based (Polyamide) film designed for advanced composite manufacturing processes such as vacuum bagging, resin infusion, and autoclave curing. It features exceptional heat stability, high elongation, and excellent barrier properties against vacuum leakage. This film is specifically engineered to fit complex, deep-draw molds without rupture, ensuring structural integrity for aerospace, wind energy, and marine components.

Key Features

Maximum use temperature 204°C, elongation >400%, reliable vacuum sealing performance.

Typical Applications

Aerospace components, wind turbine blades, high-performance automotive parts.

USP 1: Aerospace-Standard Reliability - Capable of withstanding autoclave curing cycles up to 204°C.

USP 2: Extraordinary Elongation - >400% elongation at break fits perfectly into deep-draw molds.

USP 3: Zero Leakage Guarantee - Multi-layer Nylon co-extrusion ensures perfect vacuum integrity.
